| Place of Origin: | China |
| Brand Name: | BM |
| Certification: | CE |
| Minimum Order Quantity: | 10 Square Meters |
|---|---|
| Price: | Negotiated |
| Packaging Details: | Wooden Case |
| Delivery Time: | 20 Days After Deposite |
| Payment Terms: | T/T |
| Supply Ability: | 5000Square Meters |
| Product: | Stainless Steel Cable Mesh Bags | Wire Cable: | 1.5Mm, 1.6Mm Is Popular |
|---|---|---|---|
| Mesh Opening Size: | 30x30 To 100x100Mm Or Bigger | Mesh Type: | Ferrule |
| Surface: | Black Oxide Polished | Usage: | Anti-theft Security |
Type: Inter-Woven Type, Stainless Steel ferrule type
Cable Diameter: 1.0mm,1.2mm,1.5mm,1.6mm
Mesh Size: 20 x 35mm, 25 x 45mm, 30 x 52mm, 38 x 66mm, 51 x 88mm, 60 x 104mm
Bag Size: 30*35cm, 30*60cm, 35*60cm, 50*70cm,100*70cm, 100*80cm, 82.5*120cm, other size could be customized.
Colors: stainless steel natural color, black
Features: 1. Light-weight, high-strength, free-angles curving and fold, it is discreet and portable; 2. Without toxic material, safety, environmental protection; 3. Anti-corrosive, resist the rust, can be repeated use; 4. The service life is more than 30 years.
| 1.The mesh size and diameter can be modified, so we can make the bags large or small according to your requirements. |
| 2.High strength, strong toughness, free-angles curving and fold,it is discreet and portable. |
| 3. Without toxic material, safety, environmental protection. |
| 4. Anti-corrosive, resist the rust, can be repeated use. |
| 5. Lightweight, high-strength, never rust, softness. |
| 6. fatigue resistance, impact resistance, breaking force, the overall structure of the rugged life of more than 30 years. |
1. High strength, strong toughness, free angles curving and fold, easy for transportation and installment.
2. It can bear heavy snow and glae.
3. Without toxic material, safety, environmental protection.
This product is perfect for creating Cable Mesh, Inox Mesh, and Wire Rope Mesh.
| Wire Rope Mesh Constructure | Rope Mesh Thickness | Mesh Opening | Min.Breaking Load(KN) |
| 7x19 | 1/8'' | 120x208 | 7.38 |
| 7x19 | 1/8'' | 100x173 | 7.38 |
| 7x19 | 1/8'' | 90x156 | 7.38 |
| 7x7 | 3/32'' | 100x173 | 4.18 |
| 7x7 | 3/32'' | 90x156 | 4.18 |
| 7x7 | 3/32'' | 80x139 | 4.18 |
| 7x7 | 3/32'' | 70x121 | 4.18 |
| 7x7 | 5/64'' | 100x173 | 3.17 |
| 7x7 | 5/64'' | 90x156 | 3.17 |
| 7x7 | 5/64'' | 80x139 | 3.17 |
| 7x7 | 5/64'' | 70x121 | 3.17 |
| 7x7 | 1/16'' | 80x139 | 2.17 |
| 7x7 | 1/16'' | 70x121 | 2.17 |
| 7x7 | 1/16'' | 60x104 | 2.17 |
| 7x7 | 1/16'' | 50x87 | 2.17 |
| 7x7 | 3/64'' | 80x139 | 1.22 |
| 7x7 | 3/64'' | 70x121 | 1.22 |
| 7x7 | 3/64'' | 60x104 | 1.22 |
| 7x7 | 3/64'' | 50x87 | 1.22 |
• Fixtures located above personnel
• Fixtures on mobile equipment (e.g. crane booms, derricks, drill rigs, draglines and shovels)
• Fixtures in potential impact zones of mobile equipment
• Fixtures and mountings exposed to vibration wear and fatigue
• Fixtures prone to oxidation and galvanic corrosion
• Fixtures located above important or expensive equipment
• Fixtures located in areas difficult to access for maintenance or inspection
| Product name | Anti-theft 316 stainless steel safety net |
| Common material | Rope: Stainless Steel 304 316; Ferrules: Nickel, stainless steel, Tinned Copper. |
| Cable strand | Cable Strand, 7 X 7 ( 1.5mm, 2mm.2.5mm ) ,7 x 19( 3mm,4mm). |
| Special specification | can be customed. |
| Feature | Flexibility, wear resistance, corrosion resistance. |
Our company offers top-notch technical support and services for our product. Our team of experts is available 24/7 to assist with any questions, concerns, or issues you may experience. Our services include:
We pride ourselves on providing prompt and effective solutions to ensure that our customers can maximize the benefits of our product. Contact us today for any technical support or service needs.
Product Packaging:
Shipping:
1. How to make an inquiry of wire mesh?
You need to provide material, mesh number, wire diameter, size, and the quantity to ask an offer, you can also indicate if you have any special requirement. We'll provide a formal quotation list after your inquiry received.
2. Could you provide a free sample?
Yes, we can provide a free sample in half A4 size together with our catalog. But the courier charge will on your side.
3. How is your Payment Term?
Generally, our payment term is T/T 30% in advance and the balance 70% should be paid before shipment. Other payment terms we can also discuss.
