| Place of Origin: | China |
| Brand Name: | BM |
| Certification: | CE |
| Minimum Order Quantity: | 5000 Square Meters |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Pallets |
| Delivery Time: | 8-10 Days After Getting Deposite |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 80000 Per Week |
| Item: | 358 Anti Climb Fence | Material: | Metal |
|---|---|---|---|
| Color: | Black,Green Or Customized | Post Height: | 1200Mm,1800Mm,2400Mm,etc |
| Mesh Size: | 76.2Mm X 12.7Mm | Post Material: | Steel |
| Post Size: | 60 X 60Mm,80x80Mm,100x100Mm | Post Surface Treatment: | Powder Coating |
| Wire Diameter: | 3.2mm,3.5mm,4.0Mm 5.0Mm | Post Thickness: | 2Mm |
| Surface Treatment: | Galvanized Or PVC | Package: | Pallets |
3.0Mm 4.0Mm PVC Coated Anti Climb 358 Security Fencing Black/Green
Anti Climb Security Fence Detail Description
High security fencing , Prison Mesh Fencing or 358 Mesh Fence as it is also known, is a highly robust steel Mesh Fencing system.
It consists of horizontal and vertical mesh wires which are positioned close together to prevent people from fitting their fingers
through the apertures, to ultimately climb the fencing.
Product Specification
| Fence height (m) | Panel size (Height × Width) (mm) |
Fence Post (Height × Size × Thick) (mm) |
Clamp Bar (Height × Width × Thickness) (mm) |
Middle/ corner Clamp No. (pcs) |
|---|---|---|---|---|
| 2 | 2000 × 2515 | 2700 × 60 × 60 × 2.5 | 2000 × 60 × 5.00 | 7 or 14 |
| 2.4 | 2400 × 2515 | 3100 × 60 × 60 × 2.5 | 2400 × 60 × 5.00 | 9 or 18 |
| 3 | 3000 × 2515 | 3800 × 80 × 80 × 2.5 | 3000 × 80 × 6.00 | 11 or 22 |
| 3.3 | 3300 × 2515 | 4200 × 80 × 80 × 2.5 | 3300 × 80 × 6.00 | 12 or 24 |
| 3.6 | 3600 × 2515 | 4500 × 100 × 100 × 3.0 | 3600 × 100 × 7.00 | 13 or 26 |
| 4.2 | 4200 × 2515 | 5200 × 100 × 100 × 4.0 | 4200 × 100 × 8.00 | 15 or 30 |
| 4.5 | 4500 × 2515 | 5500 × 100 × 100 × 5.0 | 4500 × 100 × 8.00 | 16 or 32 |
| 5.2 | 5200 × 2515 | 6200 × 120 × 120 × 5.0 | 5200 × 100 × 8.00 | 18 or 36 |
Manufactured with 4mm vertical wires and 4mm horizontal wires, the denseness and size of the wires provide a barrier that is difficult to pass narcotics, weapons, mobile phones and other contraband through the fence whilst also ensuring the occupants of the secure unit are kept safely and securely within the grounds of the institution.
The profiled mesh panels are supplied flat, and can be coated to a colour of choice and are also available pre-galvanised. The posts for this system are a square hollow section manufactured from high quality steel. The 356 flat mesh system / prison mesh is a must for higher security areas to prevent intruders, climbers. The thick wire and close mesh structure creates a strong and effective security fencing.
Product Application
1 Bridge anti-climb guarding & guard safety screening
2 Sub-station Security Fencing
3 Psychiatric hospital security fencing
4 Prison Security Fencing
5 Factory Machine guards
6 Walkway security fencing
7 Airport security fencing
Prison Welded Mesh Fence Features:
|
High strength welded at each intersection. |
|
Anti-climbing: more small openings, no toe or finger holds. |
|
Anti-cut: robust wire and welded joints make cutting very difficult by bolt cutters and wire cutters. |
|
Powder coating ensure a long service life. |
| Mesh fencing specially configured to provide maximum visibility, especially used for emergency and electronic detection syste |
