| Place of Origin: | China |
| Brand Name: | BM |
| Certification: | CE |
| Minimum Order Quantity: | 5000 Square Meters |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Pallets |
| Delivery Time: | 8-10 Days After Getting Deposite |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 80000 Per Week |
| Item: | 358 Anti Climb Fence | Material: | Metal |
|---|---|---|---|
| Color: | Black,Green Or Customized | Post Height: | 1200Mm,1800Mm,2400Mm,etc |
| Mesh Size: | 76.2Mm X 12.7Mm | Post Material: | Steel |
| Post Size: | 60 X 60Mm,80x80Mm,100x100Mm | Post Surface Treatment: | Powder Coating |
| Wire Diameter: | 3.2mm,3.5mm,4.0Mm 5.0Mm | Post Thickness: | 2Mm |
| Surface Treatment: | Galvanized Or PVC | Package: | Pallets |
358 Prison Mesh Fence/358 Flat Beam Prison Mesh 1.8M Security Welded Mesh Panel Barrier
Product Description
Prison mesh panel system is a high security fencing system that is anti-climb due to its 76mm wide x 12.5mm high mesh apertures (3″ x 1/2″ inch). Commonly referred to as prison mesh due to its toughness and anti-climb properties, the security fencing is supplied in 2.515m wide panels in various heights of 1.2m, 1.8m, 2.0m, 2.1m, 2.4m, 3m up to 5.2m. The flat mesh panels are galvanised and poly powder coated (PPC) in a variety of RAL colours including the popular green (RAL 6005) and black (RAL 9005).
Product Specification
| Fence height (m) | Panel size (Height × Width) (mm) |
Fence Post (Height × Size × Thick) (mm) |
Clamp Bar (Height × Width × Thickness) (mm) |
Middle/ corner Clamp No. (pcs) |
|---|---|---|---|---|
| 2 | 2000 × 2515 | 2700 × 60 × 60 × 2.5 | 2000 × 60 × 5.00 | 7 or 14 |
| 2.4 | 2400 × 2515 | 3100 × 60 × 60 × 2.5 | 2400 × 60 × 5.00 | 9 or 18 |
| 3 | 3000 × 2515 | 3800 × 80 × 80 × 2.5 | 3000 × 80 × 6.00 | 11 or 22 |
| 3.3 | 3300 × 2515 | 4200 × 80 × 80 × 2.5 | 3300 × 80 × 6.00 | 12 or 24 |
| 3.6 | 3600 × 2515 | 4500 × 100 × 100 × 3.0 | 3600 × 100 × 7.00 | 13 or 26 |
| 4.2 | 4200 × 2515 | 5200 × 100 × 100 × 4.0 | 4200 × 100 × 8.00 | 15 or 30 |
| 4.5 | 4500 × 2515 | 5500 × 100 × 100 × 5.0 | 4500 × 100 × 8.00 | 16 or 32 |
| 5.2 | 5200 × 2515 | 6200 × 120 × 120 × 5.0 | 5200 × 100 × 8.00 | 18 or 36 |
Manufactured with 4mm vertical wires and 4mm horizontal wires, the denseness and size of the wires provide a barrier that is difficult to pass narcotics, weapons, mobile phones and other contraband through the fence whilst also ensuring the occupants of the secure unit are kept safely and securely within the grounds of the institution.
The profiled mesh panels are supplied flat, and can be coated to a colour of choice and are also available pre-galvanised. The posts for this system are a square hollow section manufactured from high quality steel. The 356 flat mesh system / prison mesh is a must for higher security areas to prevent intruders, climbers. The thick wire and close mesh structure creates a strong and effective security fencing.
Product Application
1.Prison Perimeters
2.Industrial and Commercial units
3.Police stations and security areas
4.School Perimeter fencing
5.Car Parks
6.High security applications
Prison Welded Mesh Fence Features:
|
High strength welded at each intersection. |
|
Anti-climbing: more small openings, no toe or finger holds. |
|
Anti-cut: robust wire and welded joints make cutting very difficult by bolt cutters and wire cutters. |
|
Powder coating ensure a long service life. |
| Mesh fencing specially configured to provide maximum visibility, especially used for emergency and electronic detection syste |
Product Details
